Key Takeaways & Executive Findings
- •• A two-stage austenite growth model incorporating second-phase pinning and δ–γ transformation accurately predicts grain sizes in Ti microalloyed steel slabs, with average error within 5%. • Increasing Ti content from 0.02wt% to 0.04wt% significantly refines austenite grains, especially at the slab center, achieving a 27.14% average reduction. • High-temperature ferrite growth follows parabolic kinetics, but higher Ti content slows grain boundary migration during initial solidification. • The model provides a robust tool for optimizing continuous casting parameters to enhance slab quality and reduce crack defects.
Abstract
The microstructural characteristics of austenite in Ti microalloyed steel during continuous casting significantly influence the thermoplasticity, thereby affecting the quality of the slab. In this work, a prediction model for two-stage austenite growth under varying cooling rates was established by incorporating the effect of second-phase pinning and high-temperature ferrite–austenite phase transformation and growth theory. The results indicate that with 0.02wt% Ti, the high-temperature ferrite growth exhibits typical parabolic growth characteristics. When the Ti content increases to 0.04wt%, the high-temperature ferrite grain boundary migration rate significantly slows during the initial solidification stage. The predicted austenite grain sizes for 0.02wt% Ti microalloyed steel at the center, quarter, and surface of the slab are 5592, 3529, and 1524 μm, respectively. For 0.04wt% Ti microalloyed steel, the austenite grain sizes are 4074, 2942, and 1179 μm at the same positions. The average error is within 5%. As the Ti content increases from 0.02wt% to 0.04wt%, the austenite grain refinement at the center is most significant, with an average grain size reduction of 27.14%.
1. Introduction
During the continuous casting process of slabs, the evolution of microstructure is a critical factor influencing the quality of continuous casting steel [1–3]. Specifically, the coarsening of austenite grains significantly reduces the thermoplasticity of continuous casting steel [4–5]. This coarse grain size often accompanies the precipitation of primary austenite films [6–7] and carbonitrides [8] at austenite boundaries, potentially leading to crack defects during the bending and straightening processes in continuous casting. Therefore, a thorough investigation into the evolution and refinement control strategies of austenite microstructure in continuous casting processes is of paramount importance.
Currently, using activation energy of grain growth to describe grain growth behavior has become a widely adopted approach [9–12]. However, this model does not directly reflect the growth rate of grains, thereby limiting its accuracy and effectiveness in practical applications. Consequently, Hu and Rath [13] and others have further proposed models concerning grain growth rate. While these models can effectively describe the laws of grain growth, they do not fully consider the influence of precipitation of microalloying second phases during the grain growth process. Therefore, Andersen and Grong [14] combined the thermodynamic driving force of grain growth derived from experimental studies by Patterson and Liu [15]. Additionally, models developed by Eskandari et al. [16] and Nes et al. [17] describe the drag effect of microalloy element precipitation on grain growth, forming a comprehensive mathematical model.
In subsequent model developments, Yoshida et al. [18] and others proposed a two-stage growth model for low-carbon steel austenite. This model delves into the dynamic changes during grain growth, accurately describing the evolution of austenite growth in low-carbon steel. However, the model simplifies initial austenite grains as secondary dendrite arm spacing and does not consider the influence of δ–γ phase transformation on austenite grain size. In this model, the initial austenite grains are simplified as secondary dendrite arm spacing, without considering the influence of δ–γ phase transformation on austenite grain size. These models have been widely applied in describing the isothermal growth behavior of grains, particularly in the solidification and thermal processing of metallic materials [19–20]. However, they still fail to accurately depict the microstructural evolution under the cooling and reheating conditions during continuous casting. Furthermore, studies on second phase pinning typically rely on scanning electron microscopy to observe the size and precipitation amount of the second phase [21–22], neglecting the dynamic process of second phase growth and its impact on grain size.
Loading authentic research manuscript (Pages 1–5)...
Tianci Chen, Cheng Ji, Jianhua Yang, Yunguang Chi, Miaoyong Zhu (2025). Grain growth kinetics model of high-temperature ferrite and austenite in Ti microalloyed steel during continuous casting. Int. Journal of Minerals, Metallurgy and Materials (矿物冶金与材料学报). https://doi.org/10.1007/s12613-024-2991-8
Research & Educational Purpose Only:The translations, structured abstracts, analytical annotations, and data reports provided by SinoTechIntel are intended exclusively for academic research, internal corporate R&D, and educational benchmarking. They do not constitute formal engineering, chemical safety, legal, or professional advice.
Copyright & Intellectual Property Notice: Original copyright of the underlying source articles and experimental data remains with the respective authors, institutions, and original publishing journals. SinoTechIntel claims intellectual property only over its proprietary translations, analytical syntheses, and AEO structured enhancements in accordance with international fair use and academic citation principles.
Frequently Asked Questions
What is the main objective of this study?
The study aims to develop a prediction model for two-stage austenite grain growth in Ti microalloyed steel during continuous casting, incorporating second-phase pinning and high-temperature ferrite–austenite transformation, to accurately predict grain sizes and improve slab quality.
How does Ti content affect austenite grain size?
Increasing Ti content from 0.02wt% to 0.04wt% significantly refines austenite grains, especially at the slab center, with an average reduction of 27.14%. Higher Ti content slows high-temperature ferrite grain boundary migration during initial solidification.
What is the accuracy of the proposed model?
The model predictions show an average error within 5% compared to experimental measurements, indicating high accuracy in predicting austenite grain sizes at different slab positions.
Why is austenite grain size important in continuous casting?
Austenite grain coarsening reduces thermoplasticity and can lead to crack defects during bending and straightening. Controlling grain size is crucial for ensuring slab quality and preventing surface cracks.
What are the key innovations of this model compared to previous ones?
The model incorporates the dynamic effects of second-phase pinning and δ–γ phase transformation, which were often neglected. It also accounts for varying cooling rates, providing a more accurate representation of microstructural evolution during continuous casting.
