Key Takeaways & Executive Findings
- •• A novel polymer–inorganic hybrid photoelectrode (PPy@N-TiO2/CC) with a Z-scheme heterostructure was first constructed for high-efficiency photo-assisted lithium–sulfur battery (PALSB). • PPy@N-TiO2/CC acts as both a photocatalyst and an electrocatalyst, accelerating sulfur redox reactions and intermediate polysulfide conversion. • The PALSB achieves an ultrahigh discharge capacity of 1653 mAh g−1 (98.7% of theoretical) and dual-mode energy harvesting: 5 h of photo-charging delivers 333 mAh g−1. • This work integrates solar energy conversion and storage within a rechargeable battery, offering a sustainable strategy for next-generation energy storage.
Abstract
Photo-assisted lithium–sulfur batteries (PALSBs) offer an eco-friendly solution to address the issue of sluggish reaction kinetics of conventional LSBs. However, designing an efficient photoelectrode for practical implementation remains a significant challenge. Herein, we construct a free-standing polymer–inorganic hybrid photoelectrode with a direct Z-scheme heterostructure to develop high-efficiency PALSBs. Specifically, polypyrrole (PPy) is in situ vapor-phase polymerized on the surface of N-doped TiO2 nanorods supported on carbon cloth (N-TiO2/CC), thereby forming a well-defined p–n heterojunction. This architecture efficiently facilitates the carrier separation of photo-generated electron–hole pairs and significantly enhances carrier transport by creating a built-in electric field. Thus, the PPy@N-TiO2/CC can simultaneously act as a photocatalyst and an electrocatalyst to accelerate the reduction and evolution of sulfur, enabling ultrafast sulfur redox dynamics, as convincingly validated by both theoretical simulations and experimental results. Consequently, the PPy@N-TiO2/CC PALSB achieves a high discharge capacity of 1653 mAh g−1, reaching 98.7% of the theoretical value. Furthermore, 5 h of photo-charging without external voltage enables the PALSB to deliver a discharge capacity of 333 mAh g−1, achieving dual-mode energy harvesting capabilities. This work successfully integrates solar energy conversion and storage within a rechargeable battery system, providing a promising strategy for sustainable energy storage technologies.
1. Introduction
The depletion of resources and environmental pollution urge us to develop recyclable clean energy rapidly. Among various rechargeable batteries, the lithium–sulfur battery (LSB) is an ideal candidate for next-generation energy storage system owing to its high theoretical energy density (2600 Wh kg−1). However, there is still a significant gap between the actual performance of LSBs and the theoretical potential, primarily due to the sluggish/incomplete conversion of sulfur and its discharge intermediates, lithium polysulfides (Li2Sx, 4 ≤ x ≤ 8).
Fortunately, the conversion of polysulfide can be effectively promoted by introducing physical fields (such as optical fields, magnetic fields, and sound fields). Optical fields accelerate the liquid-to-solid conversion kinetics of polysulfides through photocatalytic effect, a magnetic field can optimize the mass transfer process of polysulfide through Lorentz force, while ultrasonic cavitation can significantly reduce the activation energy of polysulfide conversion. Notably, the photo-assisted strategy can not only photoelectric co-catalyze the conversion of polysulfides, but also convert solar energy into chemical energy in a single device, exhibiting promising application prospects. The design of an effective photocathode for capturing solar energy and storing it in LSBs allows photo-generated carriers to enhance the electrochemical reaction and reduce electric energy consumption, thereby facilitating the integration of solar energy storage and conversion within LSBs. However, designing an effective photoelectrode remains a significant challenge.
Research on photo-assisted lithium–sulfur batteries (PALSBs) is still in its infancy. Up to now, only a few materials have been explored that qualified for constructing photoelectrodes for PALSBs. In 2015, a CdS/Pt photocathode was fabricated to assemble PALSB, which achieved a capacity of 792 mAh g−1 after 2 h light irradiation, confirming the great potential of integrating solar energy with LSBs. Subsequently, CdS-Ti...
Loading authentic research manuscript (Pages 1–5)...
Fei Zhao, Yibo He, Xuhong Li, Ke Yang, Shuo Chen, Yuanzhi Jiang, Xue-Sen Wang, Chunyuan Song, Xuqing Liu (2026). Ultrafast Sulfur Redox Dynamics Enabled by a PPy@N-TiO2 Z-Scheme Heterojunction Photoelectrode for Photo-Assisted Lithium–Sulfur Batteries. Nano-Micro Letters. https://doi.org/10.1007/s40820-025-01946-3
Research & Educational Purpose Only:The translations, structured abstracts, analytical annotations, and data reports provided by SinoTechIntel are intended exclusively for academic research, internal corporate R&D, and educational benchmarking. They do not constitute formal engineering, chemical safety, legal, or professional advice.
Copyright & Intellectual Property Notice: Original copyright of the underlying source articles and experimental data remains with the respective authors, institutions, and original publishing journals. SinoTechIntel claims intellectual property only over its proprietary translations, analytical syntheses, and AEO structured enhancements in accordance with international fair use and academic citation principles.
Frequently Asked Questions
What is a photo-assisted lithium–sulfur battery (PALSB)?
A PALSB integrates solar energy harvesting with lithium–sulfur battery chemistry, using a photoelectrode to capture light and enhance sulfur redox reactions, thereby improving performance and enabling solar-to-chemical energy conversion.
How does the PPy@N-TiO2 Z-scheme heterojunction improve battery performance?
The Z-scheme heterostructure creates a built-in electric field that enhances charge carrier separation and transport, while PPy and N-TiO2 act as both photocatalyst and electrocatalyst, accelerating sulfur reduction and polysulfide conversion, leading to ultrafast redox dynamics and high capacity.
What are the key performance metrics of the developed PALSB?
The PALSB achieves a discharge capacity of 1653 mAh g−1 (98.7% of theoretical) and can deliver 333 mAh g−1 after 5 hours of photo-charging without external voltage, demonstrating dual-mode energy harvesting.
What is the significance of this work for sustainable energy storage?
This work successfully integrates solar energy conversion and storage within a rechargeable battery system, offering a promising strategy for sustainable and eco-friendly energy storage technologies.
What materials are used in the photoelectrode?
The photoelectrode is a free-standing polymer–inorganic hybrid consisting of polypyrrole (PPy) polymerized on N-doped TiO2 nanorods supported on carbon cloth (N-TiO2/CC), forming a p–n heterojunction with Z-scheme structure.
