Abstract
Photodetectors can convert light energy into electrical signals, so are widely used in photovoltaics, photon counting, monitoring, and imaging. Photodetectors are easy to prepare high-resolution photochips because of their small size unit integration. However, these photodetector units often exhibit poor photoelectric performance due to material defects and inadequate structures, which greatly limit the functions of devices. Designing modification strategies and micro-/nanostructures can compensate for defects, adjust the bandgap, and develop novel quantum structures, which consequently optimize photovoltaic units and revolutionize optoelectronic devices. Here, this paper aims to comprehensively elaborate on the surface/interface engineering scheme of micro-/nano-photodetectors. It starts from the fundamentals of photodetectors, such as principles, types, and parameters, and describes the influence of material selection, manufacturing techniques, and post-processing. Then, we analyse in detail the great influence of surface/interface engineering on the performance of photovoltaic devices, including surface/interface modification and micro-/nanostructural design. Finally, the applications and prospects of optoelectronic devices in various fields such as miniaturization of electronic devices, robotics, and human–computer interaction are shown.
1. Introduction
Light is one of the most important media for the transmission of information and energy, which is important for human interaction with the outside world. As a carrier, light transmits the contents of the environment to human beings, thus enabling them to establish an interactive system and make timely responses, which plays an irreplaceable role for humans. Recently, with the development of computers and artificial intelligence, light and artificial light detectors have gradually attracted widespread attention. Light detectors have similar functions to the human eyes and can convert external light information into electrical signals for computer demonstration and storage; they can also convert light energy into electrical energy as an energy converter. Therefore, the development of high-performance retinal-like photodetectors is of great significance for future artificial intelligence, human–computer interaction, and miniaturization of electronic devices.
Micro-/nano-optoelectronic devices are the main aims of photodetector development, which reduce the chip size by shrinking the optoelectronic unit while improving the signal information processing speed. However, the small size of the photodetector unit, especially the corresponding imaging unit, reduces the dynamic range and fill factor of the pixel, which is very unfavourable to the image output. Thus, the development of high-resolution sensors is also very important [1] (it is worth noting that in this paper, the resolution referred to is the lateral or longitudinal resolution based on the physical space, not the optical frequency/wavelength resolution based on the light wave). However, high resolution is very difficult to achieve because it implies more independent units per identical size of the macroscopic device, i.e. the smaller detector unit. This is usually a complex process involving precise regulation of material growth, accurate design of microstructures, innovations in photolithography, optimization of coating technology, and so on. Also, the performance of optoelectronic devices is greatly affected by defects and mismatches. Therefore, the realization of high-resolution micro-/nano-optoelectronic devices still remains a great challenge.
The small size characteristics of micro-/nano-optoelectronic devices are often based on the microscopic surface/interface; therefore, the development of surface/interface engineering is of critical significance for the optimization and innovation of the optoelectronic devices. Surface/interface engineering is mainly divided into two parts: one is surface/interface modification, mainly through chemical solvent treatment or functional group modification, so that the surface passivation or the formation of buffer layer, thus making the heterogeneous interface or the physical/chemical properties...
