Key Takeaways & Executive Findings
- •• This review describes various types of low-power memristors, demonstrating their potential for a wide range of applications. • This review summarizes low-power memristors for multi-level storage, digital logic, and neuromorphic computing, emphasizing their use as artificial synapses and neurons in artificial neural network, convolutional neural network, and spiking neural network, along with 1T1R and 1S1R crossbar array designs. • Further exploration is essential to overcome limitations and unlock the full potential of low-power memristors for in-memory computing and AI. • The paper discusses the selection of functional materials for low-power memristors, including ion transport, phase change, magnetoresistive, and ferroelectric materials.
Abstract
As an emerging memory device, memristor shows great potential in neuromorphic computing applications due to its advantage of low power consumption. This review paper focuses on the application of low-power-based memristors in various aspects. The concept and structure of memristor devices are introduced. The selection of functional materials for low-power memristors is discussed, including ion transport materials, phase change materials, magnetoresistive materials, and ferroelectric materials. Two common types of memristor arrays, 1T1R and 1S1R crossbar arrays are introduced, and physical diagrams of edge computing memristor chips are discussed in detail. Potential applications of low-power memristors in advanced multi-value storage, digital logic gates, and analogue neuromorphic computing are summarized. Furthermore, the future challenges and outlook of neuromorphic computing based on memristor are deeply discussed.
1. Introduction
Von Neumann architecture is the basic architecture of modern computers, proposed by mathematician John von Neumann in 1945. Its core idea is to store program instructions and data in the same memory block and process the data by reading and executing these instructions through a central processing unit (CPU). This architecture’s primary benefit lies in its adaptability and malleability, allowing the computer to undertake various tasks by altering programs stored in its memory [1]. However, von Neumann structure has its inherent flaws, where data storage and computing share the same channel. Such working mode limits processing speed of computer, especially if it uses dynamic random access memory (DRAM) as its primary memory. DRAM access not only requires high energy consumption, but also requires periodic refreshing. During data processing, the processor has to run continuously even while waiting for data, leading to additional energy consumption. As a result, the so-called “energy wall” and “speed wall” are formed.
As internet technology rapidly evolves, the demand for artificial intelligence is experiencing exponential growth. Artificial intelligence has achieved numerous breakthroughs in various domains, including image processing, natural language processing, and big data analysis [2–4]. The amount of data that need to be trained and processed are also increasing daily. To address this problem, complex hardware systems consisting of numerous CPUs and graphics processing units (GPUs) have been developed. As semiconductor technology is approaching its physical limits, Moore’s law is also facing failure [5, 6], and researchers must examine the constraints of von Neumann architecture through the lens of computer architecture and software algorithms. In this regard, researchers have proposed various approaches, such as the introduction of multi-level caches [7], the introduction of data streaming [8], and the proposal of in-memory computing. Among emerging technologies, in-memory computing, first conceptualized by W.H. Kautz in 1969 [9], seamlessly integrates computational functions within storage, drastically reducing the delay for data transfer. This integration further leads to reduced power consumption and improved efficiency and is hailed as the next-generation computer architecture poised to transcend the barriers of von Neumann architecture. In recent years, there has been a swift advancement in the development of novel non-volatile memory and in-memory computing technology. With high speed, low power consumption and high-density integration capability, memristor is becoming a research hotspot in in-memory computing fields. Inspired by human brain, memristors with weights updating functions are considered ideal for developing in-memory computing and artificial intelligence [10].
