Key Takeaways & Executive Findings
- •• Hydrogen-assisted mineral phase transformation enables efficient iron recovery (90.11%) from laterite nickel ore tailings, achieving a final iron grade of 61.00 wt%. • Pre-treatment at 950°C for 15 min reduces sulfur content from 2.09 wt% to 0.295 wt%, mitigating environmental hazards. • Synergistic desulfurization using wet scrubbing and limestone achieves an overall desulfurization rate of 85.83%. • The process offers a sustainable route for valorizing HPAL tailings, with potential for industrial scale-up.
Abstract
This study explores a hydrogen-assisted mineral phase transformation process with synergistic desulfurization for the efficient recovery of iron from the high-pressure acid leach (HPAL) tailings of laterite nickel ore. HPAL tailings containing 51.50wt% iron and 2.09wt% sulfur present environmental challenges due to their sulfur content. Pre-treatment at 950°C for 15 min successfully reduced the sulfur content to 0.295wt% and increased the iron grade to 57.66wt%. Further hydrogen-assisted mineral phase transformation at 520°C for 30 min, using 40vol% hydrogen and a gas flow rate of 600 mL·min–1, resulted in a product with an iron grade of 61.00wt% and 90.11% iron recovery. The overall desulfurization rate reached 85.83% when wet scrubbing and limestone were used to capture the sulfur. This study demonstrates the efficiency of this hydrogen-assisted process for sustainable iron recovery and sulfur removal from laterite nickel ore tailings, with potential for industrial applications.
1. Introduction
The rapid expansion of industries such as electric vehicles and ternary lithium-ion batteries has intensified the demand for critical metal resources, including iron (Fe), cobalt (Co), and nickel (Ni) [1–4]. With the depletion of high-grade nickel ore reserves, low-grade laterite nickel ores, which constitute approximately 75% of global nickel, have emerged as a crucial source for nickel extraction [5–7]. However, these ores have a low metal content, typically containing 0.9wt%–2.6wt% Ni, 0.01wt%–0.2wt% Co, and 40wt%–55wt% Fe, and their complex mineralogical composition renders traditional metallurgical extraction processes inefficient. High-pressure acid leaching (HPAL) is a key method for extracting Ni from laterite ores [8–10].
Despite its effectiveness in nickel recovery, HPAL produces large volumes of acid-leached tailings containing 35wt%–40wt% Fe, making it a potentially valuable secondary source of Fe. However, these tailings contain over 2wt% sulfur (S), which is a hazardous impurity that poses significant environmental and processing challenges [11–13]. The high S content not only degrades the quality of Fe recovered from the tailings but also results in the release of sulfur dioxide (SO2) during further processing, contributing to environmental issues such as acid rain [14]. Consequently, while these tailings represent an important iron-bearing secondary resource, their direct utilization is limited by both their high S content and the difficulty of economically viable processing. Currently, most tailings are disposed of in landfills or buried underground, leaving their full potential largely untapped [15].
Loading authentic research manuscript (Pages 1–5)...
Na Zhao, Yuchao Qiu, Sainan Qi, Mengyu He, Qianwen Li, Yongsheng Sun (2025). Hydrogen-assisted mineral phase transformation for iron recovery and sulfur removal from laterite nickel ore tailings. Int. Journal of Minerals, Metallurgy and Materials (矿物冶金与材料学报). https://doi.org/10.1007/s12613-025-3121-y
Research & Educational Purpose Only:The translations, structured abstracts, analytical annotations, and data reports provided by SinoTechIntel are intended exclusively for academic research, internal corporate R&D, and educational benchmarking. They do not constitute formal engineering, chemical safety, legal, or professional advice.
Copyright & Intellectual Property Notice: Original copyright of the underlying source articles and experimental data remains with the respective authors, institutions, and original publishing journals. SinoTechIntel claims intellectual property only over its proprietary translations, analytical syntheses, and AEO structured enhancements in accordance with international fair use and academic citation principles.
Frequently Asked Questions
What is the main objective of this study?
The study aims to develop a hydrogen-assisted mineral phase transformation process for efficient iron recovery and sulfur removal from laterite nickel ore tailings, addressing environmental challenges and enabling sustainable resource utilization.
How does the hydrogen-assisted process work?
The process involves pre-treatment at 950°C to reduce sulfur content, followed by hydrogen-assisted reduction at 520°C with 40vol% hydrogen, which transforms iron minerals to enhance magnetic separation and iron recovery.
What are the key results achieved?
The process achieved an iron grade of 61.00 wt% with 90.11% iron recovery, and an overall desulfurization rate of 85.83% when combined with wet scrubbing and limestone capture.
Why is sulfur removal important in this context?
Sulfur is a hazardous impurity that degrades iron quality and releases SO2 during processing, contributing to acid rain. Removing sulfur is essential for environmental compliance and improving the value of recovered iron.
What are the potential industrial applications?
The process offers a sustainable and efficient method for recovering iron from HPAL tailings, which are currently landfilled, and can be scaled up for industrial use in ironmaking and steel production.
