Key Takeaways & Executive Findings
- •• Critical tempering at 610 °C yields the best strength-ductility balance (PSE=23.6 GPa·%) in a novel cast multiphase stainless steel. • Reverted austenite stability, governed by Ms and γSFE, drives TRIP and TWIP effects, enhancing mechanical performance. • Higher tempering temperatures cause Cr segregation and Cr-depleted zones, degrading corrosion resistance. • Multiphase coordinated deformation improves strength-ductility, but corrosion initiates at chemically inhomogeneous phase boundaries.
Abstract
A novel cast stainless steel featuring a multiphase microstructure and a nominal composition of Fe-13.5Cr-2.6Si-6.9Ni-1.1Cu-1.1Mn-1.0Mo-0.35Al-0.025C (wt.%) was investigated. Following solution treatment at 1,050 °C and water quenching, the specimens were subjected to further tempering at 570 °C, 610 °C, and 650 °C to explore the effects of critical tempering on microstructure, mechanical properties, and corrosion resistance. Various characterization techniques were employed to examine the phase distribution within the microstructure, with particular attention given to the content and morphology of reverted austenite. Tensile and corrosion tests were carried out to evaluate the performance of the specimens. The results reveal that critical tempering significantly enhances the mechanical properties, with the specimen tempered at 610 °C achieving the highest product of strength and elongation (PSE=23.6 GPa·%), whereas corrosion resistance deteriorates with increasing tempering temperature. Calculations of the martensite start temperature (Ms) and stacking fault energy (γSFE) for the reversed austenite in different specimens indicate that the stability of reversed austenite strongly influences mechanical behavior through the TRIP and TWIP effects. However, tempering-induced Cr segregation at ferrite/martensite interfaces and the formation of Cr-depleted zones become more pronounced at higher tempering temperatures, leading to a degradation in corrosion resistance. Furthermore, multiphase coordinated deformation improves the strength-ductility balance, while corrosion tends to initiate at chemically inhomogeneous phase boundaries.
1. Introduction
With the growing demand for enhanced mechanical performance in steels and the challenge of overcoming the traditional strength-ductility trade-off, the construction of multiphase, multiscale, and metastable (M3) microstructures have become an increasingly popular strategy among researchers in recent years [1]. Compared with single-phase ferritic or austenitic stainless steels, duplex stainless steels exhibit superior strength and corrosion resistance. Additionally, martensitic precipitation-hardened stainless steels offer better comprehensive properties than conventional martensitic steels. Therefore, the development of multiphase stainless steels presents a promising research direction.
Several studies have demonstrated the potential of multiphase stainless steels. Tavares et al. [2, 3] reported a martensite-based triphase stainless steel containing 37% ferrite and 7.4% reverted austenite, achieving an ultimate tensile strength exceeding 800 MPa along with elongation over 20%. Liu et al. [4, 5] further increased the Ni content to approximately 5.5wt.% to enhance the austenite fraction, achieving elongations beyond 36%, and conducted detailed investigations into the corrosion and hydrogen embrittlement behaviors.
Building upon these advances, Wu et al. [6-8] developed a novel triphase stainless steel based on the PH13-8 martensitic precipitation-hardened system by introducing ferrite through high Si addition and forming reverted austenite via critical tempering after quenching. The resulting steel exhibited an ultimate tensile strength greater than 1,000 MPa and an elongation exceeding 15%. Silicon not only provides substantial solid solution strengthening but also synergizes with chromium to promote the formation of a stable oxide passive film on the steel surface, thus positively influencing both mechanical properties and corrosion resistance [9-11].
Loading authentic research manuscript (Pages 1–5)...
Jing-yu He, Guo-qiang Liu, Zi-xiang Wu, Hua-wei Zhang, Xiang Chen (2026). Effect of critical tempering on microstructure evolution, mechanical performance, and corrosion behavior of a cast multiphase stainless steel. China Foundry. https://doi.org/10.1007/s41230-026-5206-2
Research & Educational Purpose Only:The translations, structured abstracts, analytical annotations, and data reports provided by SinoTechIntel are intended exclusively for academic research, internal corporate R&D, and educational benchmarking. They do not constitute formal engineering, chemical safety, legal, or professional advice.
Copyright & Intellectual Property Notice: Original copyright of the underlying source articles and experimental data remains with the respective authors, institutions, and original publishing journals. SinoTechIntel claims intellectual property only over its proprietary translations, analytical syntheses, and AEO structured enhancements in accordance with international fair use and academic citation principles.
Frequently Asked Questions
What is the optimal tempering temperature for this cast multiphase stainless steel?
The optimal tempering temperature is 610 °C, which yields the highest product of strength and elongation (PSE=23.6 GPa·%) due to enhanced stability of reverted austenite and TRIP/TWIP effects.
How does critical tempering affect the corrosion resistance of the steel?
Corrosion resistance deteriorates with increasing tempering temperature due to Cr segregation at ferrite/martensite interfaces and formation of Cr-depleted zones, which become more pronounced at higher temperatures.
What mechanisms contribute to the improved mechanical properties?
The improved mechanical properties are attributed to the TRIP (transformation-induced plasticity) and TWIP (twinning-induced plasticity) effects, which are influenced by the stability of reverted austenite, as quantified by martensite start temperature (Ms) and stacking fault energy (γSFE).
What is the nominal composition of the investigated steel?
The nominal composition is Fe-13.5Cr-2.6Si-6.9Ni-1.1Cu-1.1Mn-1.0Mo-0.35Al-0.025C (wt.%).
Where does corrosion typically initiate in this steel?
Corrosion tends to initiate at chemically inhomogeneous phase boundaries, such as ferrite/martensite interfaces where Cr-depleted zones form.
