Key Takeaways & Executive Findings
- •• Carbonyl iron powder modification of the dielectric layer significantly enhances electromagnetic wave attenuation, achieving a broadband absorption (RL ≤ –10 dB) from 4.98 to 18 GHz covering C, X, and Ku bands. • The modified dielectric layer contributes over 30% of total power loss in the 2–18 GHz range, nearly doubling the effective absorption bandwidth compared to unmodified dielectric layers. • The absorber exhibits excellent angular stability, maintaining at least 80% absorption (RL ≤ –7 dB) up to 60° incidence across 7.0–18.0 GHz. • This method offers a simple, thin-profile manufacturing process, providing a promising alternative for broadband absorber design.
Abstract
In the field of broadband metamaterial absorbers, most research efforts have focused on optimizing the resonant layers and designing multi-layer structures, but relatively little attention has been paid to the dielectric layers themselves. This paper proposed a method using carbonyl iron powder to modify the dielectric layer. This method significantly enhances the electromagnetic wave attenuation capability of the dielectric layer with the X-band range for metamaterial absorbers. A broadband absorber with a reflection loss (RL) of less than –10 dB within the frequency range of 4.98–18 GHz and covering the C, X, and Ku band was designed. This work analyzed the surface current distribution and the power loss distribution to elucidate the absorption mechanism of the absorber. It was found that the modified dielectric layer accounted for more than 30% of the total loss in the 2–18 GHz frequency band, and the effective absorption bandwidth (RL ≤ –10 dB) was almost twice that of the unmodified dielectric layer. This enhancement in absorption bandwidth is attributed to the introduction of a new electromagnetic wave loss mechanism by carbonyl iron powder. Meanwhile, the absorber exhibited good angular stability, maintaining at least 80% absorption (RL ≤ –7 dB) in the 7.0–18.0 GHz range even when the incident angle was increased to 60°. The experimental results showed that the measured results matched the simulation results well. Furthermore, compared with other methods for broadening the absorption bandwidth, the metamaterial absorber obtained by this method offers several advantages, including wideband absorption, thin profile, and a simple manufacturing process. This approach provides a new and promising direction for the design of broadband absorbers.
1. Introduction
With the advancement of information technology, the electromagnetic environment has become increasingly intricate. In this context, the use of electromagnetic wave absorbing materials is crucial in both military and civilian sectors [1–2]. Absorbing materials can efficiently absorb and dissipate the energy of incident electromagnetic waves, thereby reducing or eliminating the reflection and transmission of electromagnetic waves [3]. This characteristic makes the wave absorbing materials widely applicable in military equipment, as well as in fields such as telecommunications [4–5], radar [6–9], wireless communication [10–11], stealth technology [12–14], and other fields.
Metamaterials [15], which are artificial material with special structures and properties, have demonstrated significant potential in the field of electromagnetic wave absorption due to their strong designability and ease of adjustment. However, challenges remain in achieving broadband absorption with metamaterials. The combination of metamaterials with traditional absorbing materials is an important approach to broaden the effective absorbing bandwidth of metamaterials [16–17]. For example, Shou et al. [18] designed an ultrathin S-band metamaterial absorber with a total thickness of 3.4 mm. The structure incorporated a magnetic top layer and a metamaterial pattern at the middle layer, achieving >90% absorption from 1.73 to 4.04 GHz. This exemplifies how hybrid designs enhance bandwidth performance. Yang et al. [19] proposed a wideband thin microwave absorbing comprising a metal-based planar metamaterial sandwiched between two lamellar carbonyl iron layers, achieving a reflection loss below –9.3 dB in the range of 3.6–18.0 GHz. Yang et al. [20] proposed a design and simulation of a composite absorber based on metamaterials and magnetic materials, with a total thickness of 4.5 mm, achieving radar cross section (RCS) reduction of 8.5 dB in the range from 300 MHz to 2 GHz and with the maximum RCS reduction of 13 dB. Lei et al. [21] has proposed a thin and light magnetic metamaterial absorber with a strong absorption performance of 23.63 dB and an effective absorption bandwidth of 2.46 GHz at a thickness of 0.9 mm. Two-dimensional Ti3CNTx-based magnetic composites have been successfully fabricated by Ma et al. [22] using the method of electrostatic self-assembly. At a thickness of 4.5 mm, an absorption bandwidth of 12.5 GHz was achieved by varying the loading of Ti3CNTx in the composite and the filling rate of the composite in the absorber, covering the frequency ranging from 5.5 to 18 GHz. Jaiswar et al. [23] proposes an ultra-wideband microwave absorber that combines a frequency-selective surface with a dielectric layer.
Loading authentic research manuscript (Pages 1–5)...
Yuan Tian, Shuo Cheng, Guoyu Yang, Xuming Yao, Long Cheng, Yujun Li, Jianjun Jiang (2025). A broadband metamaterial wave absorber based on carbonyl iron powder modified dielectric layer. Int. Journal of Minerals, Metallurgy and Materials (矿物冶金与材料学报). https://doi.org/10.1007/s12613-024-3044-z
Research & Educational Purpose Only:The translations, structured abstracts, analytical annotations, and data reports provided by SinoTechIntel are intended exclusively for academic research, internal corporate R&D, and educational benchmarking. They do not constitute formal engineering, chemical safety, legal, or professional advice.
Copyright & Intellectual Property Notice: Original copyright of the underlying source articles and experimental data remains with the respective authors, institutions, and original publishing journals. SinoTechIntel claims intellectual property only over its proprietary translations, analytical syntheses, and AEO structured enhancements in accordance with international fair use and academic citation principles.
Frequently Asked Questions
What is the main innovation of this paper?
The main innovation is the modification of the dielectric layer using carbonyl iron powder, which significantly enhances the electromagnetic wave attenuation capability and broadens the absorption bandwidth of metamaterial absorbers.
What frequency range does the proposed absorber cover?
The proposed absorber achieves a reflection loss of less than –10 dB in the frequency range of 4.98–18 GHz, covering the C, X, and Ku bands.
How does the modified dielectric layer contribute to absorption?
The modified dielectric layer accounts for more than 30% of the total power loss in the 2–18 GHz band, and the effective absorption bandwidth is almost twice that of the unmodified dielectric layer, due to the introduction of a new electromagnetic wave loss mechanism.
What is the angular stability of the absorber?
The absorber maintains at least 80% absorption (RL ≤ –7 dB) in the 7.0–18.0 GHz range even when the incident angle is increased to 60°.
What are the advantages of this method compared to other broadening techniques?
The method offers wideband absorption, a thin profile, and a simple manufacturing process, making it a promising approach for broadband absorber design.
