Key Takeaways & Executive Findings
- •• SAM achieves high accuracy in 2D discontinuity segmentation with 0.78 mean IoU and 0.86 average precision on a large dataset. • The proposed SAM-SfM framework extends identification to 3D, achieving 0.91 average precision on benchmark datasets. • The framework leverages the inherent pixel-point cloud relationship in SfM, simplifying and generalizing across photogrammetric devices. • The method provides a practical, efficient solution for rock mass discontinuity identification, valuable for geological investigations and data annotation.
Abstract
The identification of rock mass discontinuities is critical for rock mass characterization. While high-resolution digital outcrop models (DOMs) are widely used, current digital methods struggle to generalize across diverse geological settings. Large-scale models (LSMs), with vast parameter spaces and extensive training datasets, excel in solving complex visual problems. This study explores the potential of using one such LSM, Segment anything model (SAM), to identify facet-type discontinuities across several outcrops via interactive prompting. The findings demonstrate that SAM effectively segments two-dimensional (2D) discontinuities, with its generalization capability validated on a dataset of 2426 identified discontinuities across 170 outcrops. The model achieves 0.78 mean IoU and 0.86 average precision using 11-point prompts. To extend to three dimensions (3D), a framework integrating SAM with Structure-from-Motion (SfM) was proposed. By utilizing the inherent but often overlooked relationship between image pixels and point clouds in SfM, the identification process was simplified and generalized across photogrammetric devices. Benchmark studies showed that the framework achieved 0.91 average precision, identifying 87 discontinuities in Dataset-3D. The results confirm its high precision and efficiency, making it a valuable tool for data annotation. The proposed method offers a practical solution for geological investigations.
1. Introduction
A rock mass is a complex fractured system and consists essentially of two constituents: discontinuities, i.e., fractures, fissures, joints, faults, bedding planes and micro-fissures, and intact rock [1]. Discontinuities play a significant role in the mechanical properties of rock masses, since they define the weak planes in a rock mass along which the rock blocks detach and fail [2]. Therefore, the characterization of discontinuities in rock exposures is an important step required to collect input information for further rock mechanics analysis and rock engineering design.
To characterize discontinuities visible at the surface of rock outcrops, a typical set of parameters often suggested for measurement includes orientation, spacing, persistence, and roughness [3–5]. This decisive information on rock discontinuities helps to predict the flow of groundwater, assesses rock mass quality, and provides a better stability condition for rock engineering [6,7]. Traditionally, these parameters are measured manually on-site at rock exposures, for example, measuring discontinuity orientation with a compass and an inclinometer [8]. However, such methods involve trade-offs between the number of samples and labor efficiency, and are often inaccessible and dangerous. To overcome these limitations, three-dimensional (3D) digital outcrop models (DOMs) [9] offer a high-resolution digital twin of rock outcrops.
Loading authentic research manuscript (Pages 1–5)...
Jiawei Wang, Jun Zheng, Jie Hu, Xiaojin Gong, Qing Lü, Ju Han, Jialiang Sun (2025). An interactive framework integrating segment anything model and structure-from-motion for three-dimensional discontinuity identification in rock masses. SinoTechIntel Verified Research. https://doi.org/10.1016/j.ijmst.2025.09.005
Research & Educational Purpose Only:The translations, structured abstracts, analytical annotations, and data reports provided by SinoTechIntel are intended exclusively for academic research, internal corporate R&D, and educational benchmarking. They do not constitute formal engineering, chemical safety, legal, or professional advice.
Copyright & Intellectual Property Notice: Original copyright of the underlying source articles and experimental data remains with the respective authors, institutions, and original publishing journals. SinoTechIntel claims intellectual property only over its proprietary translations, analytical syntheses, and AEO structured enhancements in accordance with international fair use and academic citation principles.
Frequently Asked Questions
What is the main contribution of this paper?
The paper proposes an interactive framework integrating the Segment Anything Model (SAM) with Structure-from-Motion (SfM) for three-dimensional identification of rock mass discontinuities, achieving high precision and efficiency.
How does the framework work?
The framework uses SAM for 2D segmentation of discontinuities in images and leverages the inherent relationship between image pixels and point clouds in SfM to extend the identification to 3D, simplifying the process and generalizing across photogrammetric devices.
What are the performance metrics?
In 2D, SAM achieves 0.78 mean IoU and 0.86 average precision. In 3D, the framework achieves 0.91 average precision, identifying 87 discontinuities in the benchmark dataset.
What is the significance of this method?
The method provides a practical solution for geological investigations, offering high precision and efficiency for rock mass discontinuity identification, and is valuable for data annotation.
What are the potential applications?
The method can be applied in rock mechanics analysis, rock engineering design, groundwater flow prediction, and rock mass quality assessment, among other geological and engineering applications.
